What type of lubricating oil should be selected for the R97-1705 hard tooth reducer used in chemical machinery

The R97-1705 reducer for chemical machinery generally uses medium load industrial gear oil L-CKC220 in GB5903 L - CKC320。 The following are specific recommendations for different ambient temperatures:

When the ambient temperature is between -10 ℃ and 0 ℃, L-CKC100 can be used.

When the ambient temperature is between 0 ℃ and 10 ℃, L-CKC150 is suitable for use.

If the ambient temperature is between 10 ℃ and 20 ℃, L-CKC220 is a better choice.

For ambient temperatures ranging from 20 ℃ to 30 ℃, L-CKC320 should be selected.

When the ambient temperature is between 30 ℃ and 40 ℃, L-CKC460 can be considered.

If the gearbox operates under special conditions such as high temperature, high load, or impact load, it is also possible to choose extreme pressure industrial gear oil with better performance, such as the L-CKD series. At the same time, it is necessary to comprehensively determine the appropriate lubricating oil model based on the user manual and actual operating conditions of the reducer.
