How to choose the appropriate number of planetary gears for planetary gearboxes based on actual needs

Choosing the appropriate number of planetary gears for a planetary gearbox requires comprehensive consideration of practical needs such as load, transmission accuracy, transmission ratio, and spatial layout. The following are specific points:

Load size and characteristics

Large load: If the equipment needs to drive a large load, such as large cranes, mining machinery, etc., a planetary gearbox with a large number of planetary gears can be selected. Because more planetary gears can evenly distribute the load onto multiple gears, increasing the load-bearing capacity and reducing the pressure on each gear. For example, in large port cranes, reducers with four or more planetary gears are often used to ensure stable lifting of tens or even hundreds of tons of cargo.

Impact load: For equipment with impact loads, such as punching machines, crushers, etc., more planetary gears can enhance the ability of the reducer to cope with impacts, improve the reliability and stability of the system.

Stable load: Equipment with relatively stable loads, such as some conveyor lines, mixing equipment, etc., have relatively less strict requirements for the number of planetary gears. The number of planetary gears can be considered comprehensively based on other needs.

Transmission accuracy requirements

High precision requirements: In applications such as CNC machine tools and industrial robots that require extremely high transmission accuracy, having more planetary gears may be more advantageous. More planetary gears can make gear meshing more uniform, reduce the impact of individual gear errors on overall transmission accuracy, lower backlash, and improve transmission accuracy and stability. Generally speaking, this type of application may choose a gearbox with three or more planetary gears.

Ordinary precision requirements: For general industrial applications with low precision requirements, such as ordinary fans, water pumps, etc., the selection of the number of planetary gears can be more flexible, and can be determined based on other factors such as cost, space, etc.

Transmission ratio requirements

Large transmission ratio: Typically, with an increase in the number of planetary gears, a wider range of transmission ratios can be achieved. If a larger reduction ratio is required, such as in some devices that require a significant decrease in the speed of high-speed motors, increasing the number of planetary gears is an effective method. For example, in some textile machinery, in order to achieve the appropriate twist and tension of the yarn, a larger reduction ratio is required, and a gearbox with four planetary gears may be used to meet the demand.

Small transmission ratio: For applications that only require a small reduction ratio, the number of planetary gears can be relatively reduced to simplify the structure and reduce costs.

Space layout restrictions

Compact space: In devices with limited space, such as small automation equipment, aerospace equipment, etc., it is necessary to choose reducers with smaller volumes as much as possible while meeting performance requirements. At this time, the number of planetary gears should not be too many, as too many planetary gears will increase the size and weight of the gearbox. For example, in the transmission system of small drones, planetary gearboxes with fewer planetary gears and compact structures are usually chosen to reduce overall weight and save space.

Adequate space: If the installation space of the equipment is relatively spacious, a gearbox with a larger number of planetary gears can be considered to achieve better performance.
