What is the difference between XWE95 cycloidal pinwheel reducer and BWD4 cycloidal reducer

There are many differences between XWE95 reducer and BWD4 reducer, as follows:

Model Meaning

XWE95 reducer: XW represents a foot plate horizontally mounted dual axis cycloidal pinwheel reducer, E represents a two-stage transmission, and 95 represents the machine base number.

BWD4 reducer: BW represents a foot plate type horizontal double axis cycloidal pinwheel reducer, D represents a normal motor direct connection type, and 4 represents the machine base number.

reduction ratio

XWE95 reducer: It is a two-stage reducer with reduction ratios generally ranging from 121, 187, 253, 289, 385, 391, 473, 493, 595, 731, 841, etc.

BWD4 reducer: The reduction ratio of single-stage reducer is 9-87, the reduction ratio of two-stage reducer is 121-5133, and the multi-stage combination can reach tens of thousands.

Power range and torque

XWE95 reducer: The input power range is generally between 0.37-55kW, and the output torque range is between 150-20000N · m.

BWD4 reducer: The power range is usually 0.75-11kW, and the allowable torque is generally between 200-1800N · m.

Dimensions and weight

XWE95 reducer: The base size is relatively large, the external dimensions are relatively large, and the weight is also heavy.

BWD4 reducer: The base size is relatively small, the overall structure is compact, and the weight is relatively light.

Application scenarios

XWE95 reducer: suitable for metallurgy, mining, lifting, transportation, cement, construction, chemical, printing and dyeing, pharmaceuticals, food and environmental protection and many other fields, it can meet the requirements of various mechanical equipment for reduction transmission.

BWD4 reducer: widely used in metallurgy, mining, construction, chemical, textile, light industry and other industries, it is the preferred reducer for mechanical equipment in these industries.
